Industrial level LCD panel, suitable for continuous 24/7 operation; 4K Ultra-HD resolution; Using tamper-proof metal housing; 8ms response time for no motion blur, judder or ghosting; 1.07B colours, for a realistic and immersive visual experience; High fidelity digital processing for a brilliant and vivid video; 178°/178° extra-wide viewing angle for overall viewing performance; Professional thermal design to extend equipment lifespan; Built-in power, low energy consumption; Support multiple signals, such as VGA, HDMI, Audio ,USB multimedia, RS-232, OPS.
DISPLAY SIZE
VIEW ANGLE
BEZEL WIDTH
DISPLAY SIZE
| Specification | Details | Specification | Details |
|---|---|---|---|
| Model | |||
| Model | DHI‑LM65‑S400 | ||
| Display | |||
| Screen Size | 64.5″ | Aspect Ratio | 16:9 |
| Resolution | 3840 × 2160 (UHD) | Backlight | LED |
| Brightness | 400 cd/m² (max) | Contrast Ratio | 1200:1 |
| Display Color | 1.07 B (10 bit) | Viewing Angle | 178° (H) / 178° (V) |
| Response Time | 8 ms | Refresh Rate | 60 Hz |
| Signals | |||
| Input | VGA (D‑Sub) × 1, HDMI × 1, USB multimedia × 1, Audio In × 1, RS‑232 × 1, OPS × 1 | Output | RS‑232 × 1, Audio Out × 1 |
| Speaker | 8 W × 2 | ||
| General | |||
| Power Supply | AC 100–240 V (±10 %), 50/60 Hz, 3.5 A | Consumption | Std 170 W / Standby ≤ 0.5 W |
| Type | Internal | Net Weight | 28.5 kg (62.8 lb) |
| Gross Weight | 40 kg (88.2 lb) | Bezel Width | 23.1 mm (U/L/R/B) |
| VESA | 600 × 400 mm (23.6″ × 15.7″) | Dimension (W×H×D) | 1476.7 × 851.7 × 79.8 mm |
| Package (W×H×D) | 1660 × 1045 × 245 mm | ||
| Work Environment | |||
| Temperature | 0 °C ~ 40 °C (32 °F ~ 104 °F) | Humidity | 20 % ~ 85 % |
| Accessory | |||
| Standard | HDMI cable, Power cable, Remote control, Hanging bracket | Optional | Pedestal |
| Certification | |||
| Certifications | CE / FCC | ||
DISPLAY
Aspect Ratio
16:9
Resolution
3840×2160
Backlight
Brightness / Luminance
350nits(typ)
Contrast
3000:1
Display Colour
99% sRGB, 85% NTSC, 92% DCI-P3, 84% Adobe RGB
Viewing Angle (H/V)
178°(H)/178°(V)
Refresh Rate
60HzHz
SIGNALS
Input
HDMI 2.0×1, Type C ×1
Audio
2*10W
Output
HDMI 2.0×1, Type C ×1
GENERAL
Power Supply
19V / 6.32A, Adapter
Consumption Standard
)
Netweight
22.1kg
Gross Weight
27.3kg
Wall Mount
Dimension without stand (W×H×D)
)
Package(W×H×D)
)
ENVIRONMENT
Operating Temperature
Operating Humidity
